- No. of sandblasting functions 1 – recycle projector only.
- Nozzles 1 of ∅ 3.0 mm (∅ 3.5 mm for skeletonized on request).
- Usable abrasives OROCOR grit 46 (350µ) – SUPERCOR grit 60 (250µ) – OROBLAST 200µ
only by replacing the nozzle: CROMCOR grain 36 (500µ). - Abrasives NOT usable All ALUMINUM OXIDES – MICROBLAST 90µ and MICROFINE 55µ.
- Abrasive reserve quantity 1 complete package (8 Kg corundum – 6 Kg crystal balls).
- Operating pressure 3 – 5 BAR (40 – 70 PSI).
- Air consumption 83 liters per minute at 3 BAR – 126 liters per minute at 5 BAR.
- (if WAFIS is connected add 37 liters per minute).
- Filtration system ⇒ Dry filter bag.
- ⇒ Prepared for connection to the WAFIS also electric (A1201E).
- 42 LED Circuit Lighting with electronic transformer.
- Line voltage 230v A.C. 50 Hz (different voltages on request).
- Power consumption 9 W (if WAFIS is connected add 14W).
- 480 mm width plus space needed for the electrical cable and air tube.
- Depth 300 mm at the base – 400 maximum.
- Height 360 mm.
- Empty weight 8.5 Kg.
- Maximum size of workable detail.
⇒ Cylindrical element ∅ 120 mm x 150 mm height.
⇒ Parallelepiped 120 mm x 120 mm x 150 mm.
